| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 10200mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 13430kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CQ3316EMVG25-306 | ||
| Front/Rear Overhang | 1460/2540mm | ||
| Number of Leaf Springs | 3/3/6,9/9/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+2520+1400,1800+3000+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2020/2020,2040/2040,2060/2060mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 17/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F2CCE611C*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 235kW | 8709ml |
